矽力杰 SY8401ABC SOT23-6 DC-DC異步降壓
主要應用領域：
引腳兼容型號：
SY8401ABC.PDF
SY8401 55V高耐壓異步降壓變換器
概述：
The SY8401 develops a high efficiency asynchronous step down DC/DC regulator capable of delivering 0.8A output current. The IC adopts current mode adaptive constant off time control. The SY8401 operates over a wide input voltage range from 4.5v to 55v and integrates main switch with very low Rds(on) to minimize the conduction loss
Low output voltage ripple and small external inductor and capacitor sizes are achieved with 1.2MHz switching frequency
特性：
Low Rds(oN) for Internal N-channel Power FET:700mΩ
4.5-55V Input Voltage Range
0.8A Output Current Capability
1.2MHz Pseudo Constant Switching Frequency
Internal Soft-start Limits the Inrush Current
Hic-cup Mode Output Short Circuit Protection
EN ON/OFF Control with Accurate Threshold
Cvcle by Cycle peak Current Limit
0.6V+1% Reference Voltage
SOT23-6 Package
典型應用：
